AMF THERMATEX Antaris A

Thermatex Antaris A is a mineral tile with a painted acoustic tissue facing. In addition to its Class A sound absorption, Thermatex Antaris A also offers both fire protection and the options of hygienic treatment. As a wet-felt mineral tile it has excellent physical properties, assisting handling and installation.
Our AMF Acoustic Range carries the Declare label.

System
Exposed Grid System, demountable ceiling
Dimensions
600 x 600mm, 1200 x 600mm, 1200 x 300mm
Thickness / Weight
19 mm (c. 3.0 kg/m2)
Colour
White similar to RAL 9010
Edge details
SK, VT-S15/24
Building material class
A2-s1, d0 as per EN 13501-1
Fire protection
F30 -F90 as per DIN 4102 part 2 (according to test report)
Sound absorption
EN ISO 354  αw = 0.90 as per EN ISO 11654
NRC
0.90 as per ASTM C 423
Sound attenuation
Dn,c,w = 26 dB as per EN 20140-9 (19 mm thickness, according to test certificate)
Light reflectance
Up to 88%
Thermal conductivity λ
0.040 W/mK as per EN 12667
Humidity
Up to 95% RH
